Laser blanking production line
Our company began to develop new laser cutting blanking equipment in 2011, and obtained the national invention patent in 2013.
Using laser cutting technology of open-book blanking of a complete set of production equipment, by feeding trolley, uncoiled, leveling machine, buffer loop, servo feeder (such as servo leveling and feeding machine can replace the previous leveler and buffer loop, reducing area), laser cutting device, cutting platform, pallet device, waste treatment system, hydraulic pneumatic system and electric control system, through the system control of laser cutting head in laser cutting platform of 3 d motion cutting, instead of press and die, the realization of automatic blanking of the metal belt.
| Technical Parameters: |
| Model | CPL-3*2150 |
| Laser power | 3*6kw 3*4kw or 3*6kw |
| Focal length | 125 Auto focus |
| Operation system | Windows7 |
| Operating software | Siemens 840D sl |
| Leveling feeding rate | 0-50m/min |
| Cutting speed | 50m/min（1mmm,）Single Cutting Head |
| Raw Material Parameters: |
| Material | Common cold rolled steel plate, galvanized plate, pickling plate, 5 series, 6 series aluminum alloy plate |
| Tensile strength | 220-980MPaTensile strength: 220-980mpa |
| Sheet metal thickness | steel plate: Min0.5 – Max3.5 (mm)Aluminum plate: Min0.6 – Max3.0 (mm) |
| Coil width | 500-2150 mm |
| coil weight | 20 - 30t |
| Coil inner diameter | Φ508 mm / Φ610 mm |
| Coil outer diameter | Φ800 - Φ2000 mm |
| Finished Product Parameters: |
| Material piece length | 150-4000mm |
| Blank shape | Rectangle material, abnormity material, trapezoid piece |
| Contour precision | ±0.5 mm / m |
| Leveling precision | 1mm /m2 |
| Plant environmental and energy conditions: |
| Environment temperature | -5℃～45℃ |
| Ambient relative humidity | 80% |
| Power supply | AC3×380V±10%，50HZ±2HZ |
| Compressed air | 0.6MPa and 1.4MPa |
| Cooling water | Industrial water, industrial purified water |
