| Project | Main Parametrs |
|---|
| Basic Specification | Laser Power | 6000-30000W |
| Focal Length | F200 ~ F300mm automatic focus |
| Operating System | Windows 10(Chinese and English) |
| CNC System | FARLEY-A, FARLEY-H |
| Display System | 23.6-inch touch display (mouse operation supported) |
| Machining Range Vertical Cutting | Carbon steel/stainless steel/aluminum sheet V/Y/X/K bevel cutting ±45° |
| Processing Capability | Carbon Steel Plate Cutting Thickness(O2) | Vertically cut MAX 80mm Bevel cut MAX 30mm |
| Stainless Steel Plate Cutting Thickness(N2) | Vertically cut MAX 100mm Bevel cut MAX 25mm |
| Aluminum Steel Plate Cutting Thickness(N2) | Vertically cut MAX 100mm Bevel cut MAX 20mm |
| Processing Stroke | X Axis Stroke | MAX 28m(cutomizable) |
| Y Axis Stroke | MAX 4m(cutomizable) |
| Z Axis Stroke | 300mm |
| Processing Accuracy | X Axis Positioning Accuracy | 0.1mm/10m(≤10m),0.2mm/full length |
| YX Axis Positioning Accuracy | 0.05mm |
| X Axis Repeated Positioning Accuracy | 0.05mm/10m(≤10m),0.1mm/full length |
| Y Axis Repeated Positioning Accuracy | 0.03mm |
| Processing Speed | Maximum Acceleration | 0.8G |
| X/Y Axis Maximum Positioning Speed | 60m/min |
| X/Y Axis Maximum Linkage Positioning Speed | 84m/min |
| Power | Number of Phases | 3 |
| Rated Voltage | 380V |
| Frequency | 50Hz |
| Total Power Supply Protection Level | IP54 |
